GIC Software Functional Test Specification (SWE.4)

Note: The images in this document were generated using AI.

1 Overview

The GIC Software Functional Test Specification defines the test cases to verify the functional correctness of the GICv3 and ITS driver modules. It aims to verify the functions defined in the Detailed Design (SWE.3) and ensure the module meets the functional requirements (SWE.1).

2 Test Environment

2.1 Basic Information

| Item | Description | | :— | :— | | Test Level | Module Functional Test (SWE.4) | | Test Framework | KUnit (Kernel Unit Testing) | | Target Hardware | QEMU (virt machine) | | Kernel Version | Linux 6.12 |

2.2 System Configuration

The test environment utilizes the Linux Kernel’s KUnit framework. The GIC driver functions are tested in isolation (or with mocks) running within a QEMU virtual machine managed by the host build system.

3 Test Case

3.1 TC-GIC-FUNC-01: GIC Initialization Success

Verify gic_of_init Success Path

• Traceability: (SWE.3), REQ-GIC-INIT-01 (SWE.1)
• Description: Verify that gic_of_init returns 0 (success) when a valid Device Tree node is provided.

Input	Pre-Condition	Procedure	Expected Result
Valid device_node struct	Kernel Booted, KUnit Loaded	Call gic_of_init(valid_node, NULL)	Function returns 0.

Test Item	Input Data	Expected Result
Return Value	node with compatible="arm,gic-v3"	0
Global State	N/A	gic_data initialized.

3.2 TC-GIC-FUNC-02: GIC Initialization Failure

Verify gic_of_init Failure Path

• Traceability: (SWE.3)
• Description: Verify that gic_of_init returns an error code when an invalid Device Tree node is provided.

Input	Pre-Condition	Procedure	Expected Result
Invalid device_node struct	Kernel Booted, KUnit Loaded	Call gic_of_init(invalid_node, NULL)	Function returns -ENODEV or similar.

Test Item	Input Data	Expected Result
Return Value	node = NULL	Negative Error Code

3.3 TC-GIC-FUNC-03: ITS Device Allocation

Verify its_alloc_device

• Traceability: (SWE.3), REQ-GIC-ITS-03 (SWE.1)
• Description: Verify that its_alloc_device correctly allocates memory and assigns an ID.

Input	Pre-Condition	Procedure	Expected Result
dev_id = 10, nvecs = 2	ITS Initialized	Call its_alloc_device(its_node, 10, 2)	Function returns valid struct its_device *.

Test Item	Input Data	Expected Result
Return Pointer	dev_id=10	Non-NULL pointer
Device ID	dev_id=10	device->device_id == 10

4 Terms and Abbreviations

Terms and Abbreviations	Description
KUnit	Kernel Unit Testing Framework
DUT	Device Under Test

5 References

Documents Name	Version
GIC Software Requirements Specification (SWE.1)	1.0
GIC Software Detailed Design (SWE.3)	1.0
